| MIG
welded 'K' type frame with oval shaped tube rim 20 x
1.75/ 18 x 1.75, 28 x 28, with, carrier, side support,
chain cover, special banna type saddle with back rest,
spoke reflector. Colour : Two tone/ single in
attractive shades. |
| FRAME |
21''(50cm)ERW steel tube brazed up lugs & B.B. shell |
| FORK |
1'' stem x 24TPI swaged blaeds box crown with BCP crown cover. |
| HANDLE BAR |
Side pull brake with gripes. |
| CHAINWHEEL |
1/2''x1/8''x40/42/44/48/52-teeth with cottered crank |
| FREEWHEEL |
1/2''x1/8''x 18teeth. |
| HUB |
Front & rear oval type, 14- gauge spoke holes. |
| RIM |
28x1/2'' west wood pattern 32/40 or 36/36 spoke holes. |
| |
|
| **Accessories
shown in picture, may not be a part of standard product.
Extra price shall be charged for them, if any. |
| |
|
| |
|
|
|
| |
| FRAME |
21" ERW Steel Tube Brazed up Lugs & B.B. Shell |
| FORK |
Steel Stem M 25x1 mm Pitch Swaged Blades
Box Crown with BCP Crown Cover. |
| HANDLE BAR |
For Caliper Brake with White Grips. |
| CHAIN WHEEL |
Italy Cut 46x170mm Crank |
| FREEWHEEL |
1/2 x 118" x 18 Teeth (M 35x1 mm Pitch) or M34,70 x 1 mm Pitch. |
| HUB |
F&R Thin Barrel, 36136 Holes 14- Gauge Spoke Holes, (Made of Steel) |
| RIM |
F&R Front & Rear 26x1.112"x1.518" (44-584) Endric Pattern |
| SADDLE |
PVC Top Mounted Brown Colour with Single Coil Spring BCP |
| BRAKE |
Caliper Brake Side Pull System. |
| PEDAL |
Steel Body without Reflector M 14x1.25 Pitch |
|
| |
| |
|
| |
|
|
|
| |
|
|
